SQlab 8OX MTB stem
SQlab 8OX MTB stem
Couldn't load pickup availability
Maximum control, maximum stability and optimized weight
The SQlab 8OX stem is the perfect choice for demanding MTB riders. Developed for use on the toughest trails, it meets the high requirements of ASTM F2043-13 category 5 and is therefore approved for downhill, enduro and aggressive trail use.
The SQlab 8OX stem is designed for maximum load capacity with minimal weight. Made from high-strength aluminum, it offers an ideal combination of stability and performance, tailored to the high forces required for All Mountain and Enduro. The design is functional and reduced to the essentials for a durable, robust connection between fork and handlebar. With an angle of 6° and available in nine lengths, the 8OX allows for precise adjustment to individual geometry and seating position.
Key features:
Made from high-strength aluminum for maximum stability with minimal weight
Available in nine lengths (35–120 mm)
31.8 mm clamp diameter
Ahead cap and ahead cap screw not included in delivery
| AREA OF USE | All Mountain & Enduro |
|---|---|
| WEIGHT(S) IN G | approx. 135 / 146 / 157 / 167 / 174 / 183 |
| MATERIAL | Aluminum 7050 |
| MATERIAL SCREWS | Titanium |
| STEM ANGLE IN ° | +6 |
| LEGNTH(S) IN MM | 35 / 50 / 60 / 70 / 80 / 90 |
| REACH IN MM | 34,8 / 49,7 / 59,7 / 69,6 / 79,6 / 89,5 |
| RISE IN MM | 3.7 / 5.2 / 6.3 / 7.3 / 8.4 / 9.4 |
| CLAMP DIAMETER HANDLEBAR IN MM | 31.8 |
| CLAMPING WIDTH HANDELBAR IN MM | 50 |
| CLAMP DIAMETER HEAD TUBE IN MM | 28.6 (1 1/8") |
| CLAMP HEIGHT HEAD TUBE IN MM | 39 |
| MINIMUM HEAD TUBE OVERLAP IN MM | 32 |
| MAXIMUM TORQUE IN NM | 8 |
| E-BIKE READY | Yes |
| DIN/ASTM CATEGORIES | 5 |
